Scratch-resistant Paper Feeder

YL-650FD scratch-resistant feeder, is an auxiliary paper feeding device in the front of the folder gluer, which is suitable for the gold & silver cardboard, reverse UV, and oil polished boxes that are easy to been scratched. This feeder is linkage with the automatic folder gluer by pre-feeding paper, auxiliary paper feeding, main paper feeding and upper suction belt feeding parts.The manual pre-feeding can realize non-stop, stable and uniform paper feeding, and ensure that the final paper box su

Model： YL-650FD

Parameters

Model： YL-650FD

Mechanical Details

Scratch-resistant Paper Feeder

Main feature

● Independent motor driven,can linkage with any brand folder gluer

● Suitable for boxes with various surface treatments that are easy to be scratched (such as gold & silver cardboard,reserve UV,oil polished treatments)

● Manual pre-feeding ensure non-stop paper feeding

● The upper air suction feeding also can help avoid scratch on box surface,to improve the better quality and higher efficiency

Technical parameter

Model	Yl-650FD
Paper feeder belt height	790mm
Maximum speed of paper feeding belt	260m/min
Maximum pre feeding paper height	200mm
Minimum box size L * W	150*150mm
Maximum box size L * W	450*550mm
Dimension	261014701240mm
Power	8KW
Total mechanical weight	0.9T
Voltage	220V,3PH
Compressed air pressure	8bar
